对接XK3168仪表

XK3168仪表通讯说明

Java对接仪表

这边用的串口服务，将串口转成TCP通讯，但是解析方式是一样的。

  while (ips.read(bytes) != -1) {
                try {
                    Thread.sleep(300);
                    int length = ips.read(bytes);
                    byte[] readBuffer = new byte[length];
                    System.arraycopy(bytes, 0, readBuffer, 0, length);
                    byte valueToFind = (byte) 0xff; // 要查找的值
                    boolean found = findValue(readBuffer, valueToFind);
                    if (found) {
                        LogUtils.info("仪表", this.config.getIp(), "地磅数据 " + Arrays.toString(readBuffer));
                        // 0xff 出现的位置
                        byte[] bytes1 = new byte[5];
                        int index = lastIndexOf(readBuffer,valueToFind);
                        //LogUtils.info("仪表", this.config.getIp(), "地磅数据FF的最后一次出现位置 " + index);
                        int indexed = indexOf(readBuffer,valueToFind);
                        //LogUtils.info("仪表", this.config.getIp(), "地磅数据FF的第一次出现位置 " + indexed);
                        if (index > -1){
                            int len= readBuffer.length - index;
                            //LogUtils.info("仪表", this.config.getIp(), "地磅数据FF的最后一次出现时是否够截取的长度 " + len);
                            if (len>=5) {
                                System.arraycopy(readBuffer, index, bytes1, 0, 5);
                                LogUtils.info("仪表", this.config.getIp(), "要解析的数据 = " + Arrays.toString(bytes1));
                                int weight = MeterDadaParser.TF5ParseData(bytes1);
                                sendWeightData(weight);
                            }else {
                                if (indexed > -1) {
                                    int len1 = readBuffer.length - indexed;
                                    //LogUtils.info("仪表", this.config.getIp(), "地磅数据FF的第一次出现时是否够截取的长度 " + len1 );
                                    if (len1 >= 5) {
                                        System.arraycopy(readBuffer, indexed, bytes1, 0, 5);
                                        LogUtils.info("仪表", this.config.getIp(), "要解析的数据 = " + Arrays.toString(bytes1));
                                        int weight = MeterDadaParser.TF5ParseData(bytes1);
                                        sendWeightData(weight);
                                    }
                                }
                            }
                        }
                    }
		}
}

 public static int TF5ParseData(byte[] data) {
        int d5 = (data[1] >> 5) & 0x01; //符号
        byte GE = (byte) (data[2] & 0x0F); //个位
        int intGE= Math.abs(GE);
        byte SHI = (byte) (data[2] >> 4); //十位
        int intSHI =  Math.abs(SHI)* 10;
        byte BAI = (byte) (data[3] & 0x0F); //百位
        int intBAI =  Math.abs(BAI) * 100;
        byte QIAN = (byte) (data[3] >> 4); //千位
        int intQIAN = Math.abs(QIAN) * 1000;
        byte WAN = (byte) (data[4] & 0x0F); //万位
        int intWAN = Math.abs(WAN) * 10000;
        byte SHIWAN = (byte) (data[4] >> 4); //十万位
        int intSHIWAN = Math.abs(SHIWAN) * 100000;
//
        int number = intGE + intSHI + intBAI + intQIAN + intWAN + intSHIWAN;
        String sign = "+",    // 截取符号位
                reading = String.valueOf(number),    // 截取数据位
                fraction = "";    // 截取小数位
        if (Cache.isDebug) {
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, StrUtil.format("数据位:{},符号位:{},读数为:{},小数位:{}\r\n", data, sign, reading, fraction));
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, d5 + " 符号");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intGE + " 个位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intSHI + " 十位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intBAI + " 百位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intQIAN + " 千位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intWAN + " 万位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, intSHIWAN + " 十万位");
            LogUtils.warn(LogUtils.DEVICE_TYPE_YB, number + " KG");
        }

        return Integer.parseInt(MeterDataUtil.packageData(sign, reading));
    }
